Vertical Milk Cooling Tank
300 - 500 - 1000 - 1500 - 2000 LITERS
TECHNICAL SPECIFICATIONS
Material Standard: CrNi 304 Quality Food Grade Stainless Steel
Internal Wall Thickness: 1.5 mm
External Wall Thickness: 1.0 mm
Cooling Plate: 2 mm thick base plate
Cooling Technology: Integrated cooling surface with Rollbond system and laser welding
Welding Technology (General): Laser and argon welding, smooth and hygienic surface quality
Insulation Material: 50 mm water-based, high density polyurethane
Chassis Type: Monoblock structure integrated under the tank
Mixer Power: 25 W
Mixer Speed: 28 rpm (rpm)
Mixer Structure: Stainless steel impeller with reducer
Discharge Feature: Zero flow discharge design
Product Outlet Valve: Butterfly valve (dimension options: DN32, DN40, DN50)
COOLING SYSTEM
- Fast cooling without freezing
- R-404A gas
- 35 °C - 4 °C cooling capacity
- (at 32-38 °C ambient temperature)
OPTIONAL EQUIPMENT
- Digital weighing system (load cell)
- Milk transfer pump (milk transfer pump assembly)
ELECTRICAL GROUP
- IP65 protection class panel
- 220V or 380V operation
- digital thermometer
- Electronic control card and phase protection relay
- Automatic mixing program: 5 min on / 10 min stop
